Modern Transport Engineers (MTE) 3 ROWS OF 8 LINKWING Truck Not Included

The 3 Rows of 8 Linkwing is our most popular trailer. With an 80,000kg GVM, hydraulic widening and hydraulic suspension. It has the added bonus of being able to clip on more of 8’s to handle any job. The linkwing can raise, lower, widen its decks and can be optioned with a internal hydraulic gooseneck. The linkwing is fully customisable to meet your individual transport needs.

STANDARD SPECIFICATIONS (APPROX)

Deck Length: 10,800mm
Deck Height: 900mm
Widening: 2500mm Closed · 4270mm Open
Opening Widths: 2500mm, 2700mm, 3100mm, 3500mm, 3750mm, 4000mm, and 4270mm
Axles: MTE 17.5? Ten stud 225 PCD
Axle Spacing: 1830mm – 1830mm
Axle Retraction: Axle retraction to all axles to facilitate maintenance
Suspension: MTE Hydraulic suspension with NEW low maintenance quick change rams
Brakes: 12-1/4? x 5-1/2? brakes on outboard drums
Tyres: 215 x 17.5? 16ply
Wheels: Steel wheels
Spare Tyre Carriers: 2
Power Source: Truck
Lighting: HELLA LED lights to ADR 4198 with 1 rotating light in ramp
Rub Plate: Two-position oscillating
Rub Plate Height 1300mm
Gooseneck: Fixed Height
King Pin: 3-1/2? MTE drop-in king pin
Ramps: 2700mm x 900 Hydraulic
Toolboxes: Two open toolboxes on each side of trailer
Chain Bins: Two chain bins on spine of trailer
Link Pins: 150mm diameter front link pins – 100mm diameter near link pins
Signage: ‘Do not overtake’ and ‘OVERSIZE’
Landing Legs: Heavy duty
Deck Material: Western Australia heavy duty with two x wear straps on neck, 10mm thick deck

OPTIONAL EXTRAS (APPROX)

Wheels : Aluminium wheels machined finish
Wheels: Aluminium wheels polished finish
Tyres: Specific branded Tyres (Please State)
Ramps: Heavy duty Ramps 1050 x 3000mm
Ramps: Double fold ramps 3700 x 900mm
Ramps: Double fold ramps 4400 x 900mm
Greasing: Centralised greasing – brakes and suspension
Greasing: Centralised greasing with timer – brakes and suspension
Greasing: Manual greasing system 8 points per suspension out to a manual block
Remote Control: 12 Function remote system for operating Gooseneck, Suspension & Widening
Ship Locks: Ship-lock pockets for 20' and 40' containers & 4 x double-ended ship locks
Power Pack: 5.5 HP Diesel power pack, electric start with battery
Power Pack: 5.5 HP Petrol power pack, pull start only
Power Pack : 5.5 HP Petrol power pack, electric start with battery
Gauges: Gauges for load indication
Storage: 6x Lockable toolboxes (3 on each side)
Water Tank: Stainless steel water tank and tap
Rub Plate: Sliding rub plate
Gooseneck: Hydraulically adjustable compensating gooseneck
Kingpin: MTE 50mm drop-in Kingpin
Odometer: Hub odometer
Deck: Longer deck – 11,900mm Deck Length
Deck: Longer deck – 12,550mm Deck Length
Extendable: Extendable – 3-Meter extension with 12,540mm Overall deck Length. (Extends in 500mm increments)
Extendable: Extendable – 4-Meter extension with 13,550mm Overall deck Length. (Extends in 500m increments)
Clip On: Clip-on 4th axle
Drop Bed: 125mm
Widening: Cylinder on spine to assist widening

Please Contact us more details on this trailer.

office OR

PRICE EXCLUSIVE OF GST
PRICE ON APPLICATION

Sandblasting, Painting & any Modifications can be made if required

*Optional extras may be shown in photos. To be used as a guide only.
