Seller's Comment
ULTIM 25.5kl COMPOSITE DG ROAD TANKERS
Pricing starting from $275,000
Model Number: FRTVT173/255
Constructed in vinyl ester resin corrosion barrier and isophthalic resin structural layers
Tank Dimensions: 1730mm dia x 11,300mm overall length
| Item | Description |
| 25.5KL Composite Tanker | Manufactured to BS4994 & AS234 Corrosion resistant internal barrier, vinyl ester resin Structural layers, isophthalic resin Highly waxed internal finish for premium flush out Polyurethane external finish, white 10 year corrosion warranty (conditions apply) 10 year structural warranty (conditions apply) |
| Approvals & Rating | DG rated. EPA approved |
| Duty | Full vacuum and pressure rated (TBC) Suitable for waste liquids, highly corrosive substances (see resin compatibility chart) |
| Baffles | 4 x Compartment, 5 x baffles |
| Manway Hatches | 4 x 450mm Mild steel, chemical resistant coating |
| Flanges (from tank) | Up to 10 off Note – fill nozzle in centre, rear (remove spill tray) |
| Valves & Fittings | Stainless Steel 304 |
| Hose Trays | 1 x Full length stainless steel 304 hose tray 1 x 3.5m stainless steel 304 hose tray (driver’s side) Hinged doors on each for easy access Lowered to mudguards (150-200mm lower than existing) Hooks for securing bungee cords |
| Loose Hoses | 6 off DN100 x 3000mm long hoses Assorted camlock configurations |
| Access | FRP walkway and ladder Ladder to be set back and on slight angle |
| Lights | Safety gate Grip tape Work lights (switch at rear of trailer): 2 x facing rear, 2 x facing each side Flashing Beacons – 2 off (rear and front) |
| Reversing Camera | Included |
| Rollover Frame/Cradle | Powdercoated steel |
| Sight Glass | At rear of tank New design to eradicate pinch points |
| DG / EIP Signs | Fitted and supplied |
| Labelling | Bracketed, pop-riveted engraved stainless |
| Registration | Fully registered |
| Documentation | Operating & Training Manual Test Reports Design & Layout Drawings System Schematics Resin compatibility chart |
| Model/Trailer Type | ST-3 Tri Axle Skel Trailer |
| Deck Dimensions | Skel Trailer |
| Width Dimensions | 2490mm |
| Chassis | Fully fabricated 130 x 12mm top flange & 130 x 16mm bottom flange |
| Axles | Hendrickson Intraax 20†Axle HXL7-Cast Drums |
| Suspension | Hendrickson AANT230 Intraax 15†RH |
| Dump Valve | Wabco raise/lower valve kit |
| Rims | 22.5†x 10 Alcoa Durabrite Outer Level 1 inners 285 PCD |
| Tyres | 11 R/22.5 Dunlop |
| Brakes | Hendrickson Disc Brakes |
| Towing Eye | 1 position king pin |
| Paint Work | Fully sandblasted with Polyzinc undercoat & powder coated topcoat – skel trailer |
| Paint Color | Black |
| Lights (Trailer) | LED lucidity semi trailer light kit |
| Drop Leg | 2 x 12,500kg dual speed to suit dropdeck trailer – Jost Modul |
| GVM | 38,000kgs |
| Toolboxes | 2 x 600x450x450mm Powdercoated, stainless steel lid Positioned at rear of trailer |
| Mudguards | Plastic full guards to suit tri-axle skel |
| Weighing Scales | Wabco Smartboard |
| Warranty (Trailer) | 2 years |
| Configuration | Skid mounted (streamline current design) Fitted high up into skel as possible for max. clearance Mounted with suspension brackets |
| Pump | Pompetravaini Liquid Ring Vacuum Pump TRVX1001007 - Stainless steel rotor and port plates, carbon steel housing - Operating speed: 1500rpm - Operating pressure: +90kPa - Operating vacuum: -90kPa Full stainless steel |
| 4-Way Valve | Manual To select pressure/vacuum operation Supplied loose 4m x DN100 Hose |
| Vacuum Relief | For pump cooling |
| Pressure Valve | Controlling max. vacuum Controlling max. pressure DN63 Fitted to rear of tank |
| Primary & Secondary Trap | FRP construction Float valves Stainless steel fittings |
| Process Water Tank | Stainless steel For storage/separation Fill connection with valve Level connection with valve Cleanout port Sight tube |
| Diesel Engine | Hatz 4L41C-103C 4 Cylinder Silent Pack (TBC) Deep sea electronics engine management system (control box) Direct drive (via drive coupling between engine and pump) Engine start battery |
| Fuel Tank | 90L Aluminum fuel tank Sight level glass |
| Venting | Automatic venting |
| Control Panel | As per existing builds Kill switch/key |
| Warranty (System) | 1 year |
